LX Wall Mount System
Build stronger connections with patients—while comfortably completing documentation—with this complete workstation. Easily reposition your screen or keyboard up and down or side to side to keep eye contact with your patients. The wall mount system supports an LCD, keyboard and a CPU with a compact footprint that fits in tight spaces.
NOTE: Select CPU size to get part number details.
PART NUMBER: 45-253-026, 45-247-026
Brand
Deskripsi
Build stronger connections with patients—while comfortably completing documentation—with this complete workstation. Easily reposition your screen or keyboard up and down or side to side to keep eye contact with your patients. The wall mount system supports an LCD, keyboard and a CPU with a compact footprint that fits in tight spaces.
NOTE: Select CPU size to get part number details.
PART NUMBER: 45-253-026, 45-247-026
Fitur
Manfaat
- More motion
Offers 13″ of height adjustment with full tilt and pan - Ergonomic set-up
Back-tilt keyboard tray protects wrists from pain or injury - Saves space
Folds within inches of the wall when not in use - Large extension
Offers 25″ of screen extension and 35″ of keyboard tray extension - Flexible installation
Just loosen the screws to change the arm location on the Wall Track - Quality design
Built for thousands of movements by passing 10,000-cycle test
Spesifikasi
| Part Number | 45-253-026 (Small CPU Holder), 45-247-026 (Medium CPU Holder). |
| Description | LX Wall Mount System (polished aluminum). Includes 10″ and 34″ Wall Tracks with two black track covers, LX Wall Mount LCD Arm, LX Keyboard Arm, wrist rest, mouse pad, mouse holder, Small CPU Holder, two 10″ Cable Channels, mounting kits for hollow-wall and wall-stud installation. Polished aluminum construction offers greater durability and enhanced aesthetics. Snap-fit cap secures interface of arms to extensions for greater stability. Base includes theft deterrent anchor holes for cable locks. |
| Quality Tested | 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment. |
| Weight Capacity | display = 7–25 lbs (3.2–11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 40 lbs (18 kg). With monitors greater than 20 lbs (9.1 kg) in weight, the vertical range of motion may be reduced up to 4.5″ (11 cm) for a total height range of 8.5″ (22 cm). |
| Mounting Standards | VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm). |
| CPU Size Range | Small CPU: 1-3/8″ to 3-3/4″ (35 to 95 mm) wide. Medium CPU: 3-3/8″ to 8″ (9 to 20 cm) wide; CPUs down to 2″ (5 cm) wide can be accommodated by installing the included CPU spacer within the holder. |
| Product Weight | 29.6 lbs (13.4 kg). |
| Shipping Dimensions | 37″ x 22″ x 7.5″ (94 x 56 x 19 cm). |
| Shipping Weight | 40 lbs (18 kg). |
| Warranty | Ten years. |
